Trotec BO26 Videoscope
Trotec BO26 Videoscope
- Light, easy-to-handle compact device with semi-rigid gooseneck probe
- Memory function to take individual photographs or record complete video sequences
- Water-proof camera head (IP67 type of protection)
FIND YOUR TROTEC STOCKIST HERE:
Quick endoscopic photo or video documentation
The BO26 enables the visual inspection even in poorly accessible locations which for the purpose of documentation can not only be saved in form of photos but also as video sequences and can be watched via an external TV screen or transferred to a PC, if required.
The 360° image rotation function, the supplied side-view mirror attachment and the powerful quad LED illumination with variable brightness ensure significant photos and videos in every inspection environment.
Despite its versatility the BO26 is characterized by uncomplicated handling:
A multilingual on-screen menu and many clever parameters such as exposure or focusing of the target area, which are predefined or integrated directly in the device’s CMOS sensor, promote a simple, intuitive operation.
| Technical data | ||
|---|---|---|
| General information | ||
| Article number | 3.510.009.126 | |
| Display | ||
| TFT | ||
| Colour | ||
| Size | 3.5 inch LCD (320 x 240 pixels) | |
| Power supply | ||
| Internal (battery) | 1.800 mA Li-Ion battery | |
| External (USB) | ||
| External (power adapter) | ||
| Internal (battery) | ||
| Device control | ||
| Keys | ||
| Ambient conditions | ||
| Operation - min. temperature [°C] | 0 | |
| Operation - max. temperature [°C] | 50 | |
| Operation - max. relative humidity [% RH] | 80 | |
| Type of protection probe with measuring head | ||
| IP67 | ||
| Memory organisation | ||
| SD card | ||
| Internal flash [MB] | ||
| Interfaces | ||
| Video out (composite video) | ||
| 3.5 mm jack (video/audio in/out) | ||
| USB (type mini, 5-pin) | ||
| Video norm | ||
| PAL | ||
| NTSC | ||
| File format | ||
| Snapshot | JPEG | |
| Video | MPEG-4, AVI, 3GP | |
| Housing design | ||
| Plastics | ||
| Metal | ||
| Dimensions | ||
| Length (packaging excluded) [mm] | 255 | |
| Width (packaging excluded) [mm] | 85 | |
| Height (packaging excluded) [mm] | 110 | |
| Weight | ||
| (packaging excluded) [kg] | 0.84 | |
